Technical parameter
Model |
Capacity |
Electric power(KW) |
Jacket capacity |
Diameter inner pot φ(mm) |
Outside the pot diameter R(mm) |
Total power(kw) |
Stirring speed(r/min) |
FE50 |
50L |
3χ2 |
95 |
400 |
600 |
1.1 |
50-80 |
FE100 |
100L |
6×2 |
120 |
500 |
700 |
1.1-1.5 |
50-80 |
FE200 |
200L |
6×3 |
200 |
600 |
800 |
1.1-2.2 |
50-80 |
FE300 |
300L |
6×3 |
250 |
700 |
900 |
1.5-3 |
50-80 |
FE500 |
500L |
9×3 |
290 |
900 |
1100 |
2.2-4 |
50-80 |
FE1000 |
1000L |
9×4 |
560 |
1200 |
1400 |
3-5.5 |
50-80 |
FE2000 |
2000L |
12×4 |
750 |
1300 |
1500 |
5.5-7.5 |
50-80 |
FE3000 |
3000L |
15×5 |
1015 |
1500 |
1700 |
5.5-11 |
50-80 |
FE4000 |
4000L |
15×5 |
1226 |
1600 |
1800 |
11-15 |
50-80 |
Broadly understood reactor, i.e. there is a physical or chemical reaction vessel of stainless steel.Stirring allows two or more different materials dispersed among each other to each other, so as to achieve uniform mixing; also can accelerate heat and mass transfer processes.In industrial production, most of the stirring operation is mechanical stirring. Mixing equipment consists of a stirring device, shaft seals and mixing tanks three major components.Stainless steel reactor is widely used in petroleum, chemical, rubber, pesticides, dyes, medicines, food and other production-oriented user andResearch projects of various scientific experiments, for complete hydrolysis, neutralization, crystallization, distillation, evaporation, storage,alkylation,Polymerization, condensation, heating container mixed, heated reaction the process.We can give you affordable stirred tank reactor.All products have to go through five checks in the whole process.We believe that the quality is the soul of an enterprise.
